TK NC drill bit for pre-drilling 90°

material: sintered carbide

Number of cogs -2

  • Fine structure of VHM
  • Clamping - smooth shank
  • Helix angle 20°
  • Machining direction

You will be asked for adding the blank attributes when placing the goods in the basket.

Centring NC drill bit for hole pre-drilling with tip angle 90° or another angle on customer request.

  • peak angle can be adapted to customer needs
  • dimensions L1, L2 – adaptable to customer needs
  • cutting conditions - see Cutting Conditions
  • express completion is subject of surcharge, see Sharpening

Mass-produced dimensions:

Product code
d1 h10 mm
d2 h6 mm
I2 mm
I1 mm
Weldons
Price excl. VAT
Purchase
22.22.032
3,00
3,00
8,00
40,00
€ 12.28
pcs
22.22.042
4,00
4,00
12,00
51,00
€ 15.68
pcs
22.22.052
5,00
5,00
12,00
51,00
€ 18.16
pcs
22.22.062
6,00
6,00
12,00
51,00
€ 20.56
pcs
22.22.082
8,00
8,00
20,00
59,00
€ 29.17
pcs
22.22.102
10,00
10,00
26,00
80,00
€ 40.19
pcs
22.22.122
12,00
12,00
26,00
84,00
€ 51.96
pcs
22.22.162
16,00
16,00
32,00
93,00
€ 89.20
pcs
22.22.202
20,00
20,00
36,00
105,00
€ 125.06
pcs
