Monolithic hard-metal copying and radius mills ALU Z4

material: sintered carbide
helical line angle 30° standard
z = 4 two cogs to the centre / 1 cog to the centre
Number of cogs -4
medium

  • Fine structure of VHM
  • Four-edged cutter
  • Milling in all directions
  • Aluminium alloys
  • Clamping - smooth shank
  • Cooling
  • Helix angle 30°

You will be asked for adding the blank attributes when placing the goods in the basket.

Universal radius and copying mills with special-design geometry for machining particular materials according to customer order.

  • dimensions L1, L2, d1, d2 - can be adapted to customer request
  • cutting conditions - see Cutting Conditions
  • express completion is subject of surcharge, see Sharpening
  • manufacture from 1 piece up
  • a discount is provided in the case of purchase of multiple tools of the same type.

Mass-produced dimensions:

Product code
d1 h10 mm
d2 h6 mm
I2 mm
I1 mm
Weldons
Price excl. VAT
Purchase
15.42.032.1
3,00
3,00
8,00
40,00
€ 23.01
pcs
15.42.042.1
4,00
4,00
12,00
51,00
€ 23.98
pcs
15.42.052.1
5,00
5,00
12,00
51,00
€ 25.45
pcs
15.42.062.1
6,00
6,00
12,00
51,00
€ 28.43
pcs
15.42.082.1
8,00
8,00
20,00
59,00
€ 35.23
pcs
15.42.102.1
10,00
10,00
26,00
80,00
€ 44.59
pcs
15.42.122.1
12,00
12,00
26,00
84,00
€ 57.32
pcs
15.42.142.1
14,00
14,00
26,00
84,00
€ 87.63
pcs
15.42.162.1
16,00
16,00
32,00
93,00
€ 102.33
pcs
15.42.182.1
18,00
18,00
36,00
93,00
€ 126.81
pcs
15.42.202.1
20,00
20,00
36,00
105,00
€ 150.87
pcs
15.42.252.1
25,00
25,00
36,00
110,00
€ 203.28
pcs
15.42.322.1
32,00
32,00
32,00
110,00
€ 293.34
pcs
